量程 Capacity

0-50,100, 200, 300, 500, 1000, 2000kg

材质 Material

不锈钢或合金钢Stainless Steel or alloy steel

输出活络度 Rated Output

1.0 ± 10% mV/V

综合精度 Total Accuracy

0.5 % F.S.

零点输出  Zero Balance

±2 %F.S.

绝缘电阻  Insulation

≥5000MΩ/100VDC

非线性 Non-linearity

0.5%F.S.

使用电压 Recommended Excitation

3-10V

滞后 Hysteresis

0.3%F.S.

响应频率 Response Frequency

300Hz

沉复性 Repeatability

0.1%F.S.

温度赔偿领域 Compensated Temp Range

-10~60℃

蠕变 （30分钟）Creep (30min)

0.1%F.S.

工作温度 领域 Operating Temp  Range

-20~80℃

温度活络度漂移Temp Effect on Output

0.05%F.S./10℃

安全超载 Safe Load Limit

150%

零点温度漂移 Temp Effect on Zero

0.05%F.S./10℃

极限超载 Ultimate Load Limit

300%

输入输出电阻

Input/Output Impedance

750±10Ω/750 ± 3Ω

电缆线尺寸 Cable Size

 φ3(4)x 3m

TEDS  可选
