量程 Capacity

0 ~ 1,2,3,5NM

材质 Material

铝 Aluminum

输出活络度 Rated Output

1.0~1.5 mV/V

综合精度  Total Accuracy

0.5% F.S.

零点输出  Zero Balance

± 2 % F.S.

绝缘电阻  Insulation

≥5000MΩ/100VDC

非线性 Non-linearity

0.3% F.S.

使用电压 Recommended Excitation

3~10V

滞后 Hysteresis

0.1% F.S.

沉复性 Repeatability

0.1% F.S.

温度赔偿领域 Compensated Temp Range

- 10 ~ 60 ℃

蠕变 （30分钟）Creep (30min)

0.1% F.S.

工作温度 领域 Operating Temp  Range

- 20 ~ 80 ℃

温度活络度漂移Temp Effect on Output

0.05% F.S. / 10℃

安全超载 Safe Load Limit

120%

零点温度漂移 Temp Effect on Zero

0.05% F.S. / 10℃

极限超载 Ultimate Load Limit

150%

输入/输出电阻 Input/Output Impedance

350 ± 10Ω / 300 ± 3Ω

电缆线尺寸 Cable Size

φ2 x 3m

电缆线衔接方式Wire Connection

Ex + : 红 Red;   Ex - : 黑 Black; Sig + : 绿 Green; Sig - : 白 White
